SPIRTEX
SAE 100 R4 SUCTION AND DELIVERY HOSE
KEY FEATURES
- Hardwall hose used for the suction and delivery of hydraulic oils
- High robustness of hose structure
- Long lasting in severe applications
- Resistance to Vacuum
- Improved minimum bend radius
- Max. length: 60m
APPLICATIONS & FLUIDS
- Hydraulics: suction lines, return lines
- Mineral oils, vegetable and rape seed oils, glycol and polyglycol based oils, synthetic ester based oils, oils in aqueous emulsion, water
CONTINUOUS SERVICE TEMPERATURE RANGE
-40 °C, -40 °F
100 °C, 212 °F
TUBE
NBR synthetic rubber
REINFORCEMENT
High tensile synthetic cord, helix body wire
COVER
Weather resistant synthetic rubber
APPLICABLE SPECS
SAE J517 100 R4, Manuli® Design; two-thirds the SAE J517
100R4 minimum bend radius
TYPE APPOVALS
CU-TR
DISCLAIMER:
We reserve the right to modify our products and/or related services and/or discontinue the manufacture and/or supply of any of the products and/or related services, without notice. This document supersedes all previous versions and previously issued documentation. The only official source of technical crimping parameters regarding our products is our Digital Crimp Tools. Printed copies are uncontrolled therefore, please be sure to use the latest versions of our Manuli Crimp App or Manuli Crimp Web Tool. Don’t mix and match: always use original hoses and fittings. For more information, see our ‘Safety Guide’.
