COOLER/5

INDUSTRY & GENERAL PURPOSE WATER COOLING HOSE

KEY FEATURES
• Hardwall suction and delivery structure
• Compact, lightweight and extremely flexible
• Robust hose structure for longer life in severe applications
• Long length assemblies available – Max length: 40m (DN16 to DN76); 20m (DN102)

APPLICATIONS & FLUIDS
• Suction & delivery of hot air and water in engine cooling systems

CONTINUOUS SERVICE TEMPERATURE RANGE
-60 °C, -76 °F
200 °C, 392 °F

TUBE
Red, VMQ silicone

REINFORCEMENT
High tensile synthetic cord and steel helix body wire

COVER
Red VMQ sliicone, high temperature and weathering resistant

APPLICABLE SPECS
Manuli design, safety factor 3:1

STANDARD PACKAGING
Coil
