FUELTANKER/10 SD

SUCTION & DELIVERY HOSE FOR FUEL AND MINERAL OIL

KEY FEATURES
• Hardwall suction and delivery structure
• Compact, lightweight and flexible
• Extreme abrasion resistance
• Designed for tankers
• Long length assemblies available – Max length: 40m

APPLICATIONS & FLUIDS
• Suction & delivery hose for mineral oils, diesel fuel and gasoline with aromatic contents up to 50%
• Very light and flexible
• Extraordinarily resistant to abrasion
• Ideal for fuel distribution company road tankers

CONTINUOUS SERVICE TEMPERATURE RANGE
-40 °C, -40 °F
80 °C, 176 °F

TUBE
Black NBR anti-static rubber

REINFORCEMENT
High tensile synthetic cord and 1 copper wire for grounding

COVER
Black, smooth, glossy NBR/PVC rubber with red thermoplastic spiral, resistant to abrasion, ozone and weathering

APPLICABLE SPECS
Manuli design, safety factor 3:1

STANDARD PACKAGING
Coil

REMARKS

• Hose wall thickness: DN 51: 4.5mm; DN 63 & DN 76: 5.0mm; DN 102: 7.0mm
• Red thermoplastic spiral diameter: DN 51 & DN 63: 6mm; DN 76 & DN 102: 8mm
